D-Link DI-3660 [503/506] Display l2tp event information
![D-Link DI-3660 [503/506] Display l2tp event information](/views2/1206859/page503/bg1f7.png)
Command Line Interface Reference Manual
503
４６
ｉｎｐｕｔ ４６，ｓｅｌｅｃｔ ｖｐｄｎ：
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｇｒｏｕｐ ｄｉｓｐｌａｙ ＶＰＤＮ ｇｒｏｕｐ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ｇｒｏｕｐ
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Ｔｈｅ ｓｃｒｅｅｎ ｗｉｌｌ ｄｉｓｐｌａｙ ｔｈｅ ｂｅｌｏｗ ｓｉｍｉｌａｒ ｉｎｆｏｒｍａｔｉｏｎ：
！
ｖｐｄｎ ｅｎａｂｌｅ
！
ｖｐｄｎ－ｇｒｏｕｐ １
ａｃｃｅｐｔ－ｄｉａｌｉｎ
ｆｏｒｃｅ－ｌｏｃａｌ－ｃｈａｐ
ｌｃｐ－ｒｅｎｅｇｏｔｉａｔｉｏｎ
ｔｅｒｍｉｎａｔｅ－ｆｒｏｍ ｌａｃ
ｌ２ｔｐ ｈｉｄｄｅｎ
ｌ２ｔｐ ｔｕｎｎｅｌ ａｕｔｈｅｎｔｉｃａｔｉｏｎ
ｌｏｃａｌ－ｎａｍｅ ｂｄｃｏｍ
ｐｒｏｔｏｃｏｌ ｌ２ｔｐ
11.19 display L2TP event information
display the control information during establishing L2TP tunnel and session. Relative command as below:
command function
Ｄｅｂｕｇ ｌ２ｔｐ ｅｖｅｎｔ display L2TP event information
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｅｎａｂｌｅ／］＃ｄｅｂｕｇ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ａａａ Ｄｅｂｕｇ ＡＡＡ ｐｒｏｃｅｓｓ ｉｎｆｏｒｍａｔｉｏｎ
．．．．．．
（１２）ｉｐ ＩＰ ｉｎｆｏｒｍａｔｉｏｎ
（１３）ｊｏｂ Ｄｅｂｕｇ ｊｏｂ ｉｎｆｏｒｍａｔｉｏｎ
（１４）ｌ２ｔｐ Ｌ２ＴＰ ｉｎｆｏｒｍａｔｉｏｎ
（１５）ｌａｐｂ ＬＡＰＢ ｉｎｆｏｒｍａｔｉｏｎ
（１６）ｌｉｎｅ ｒｅｃｖ ａｎｄ ｓｅｎｄ ｄａｔａ ｏｎ ｌｉｎｅ
－－Ｍｏｒｅ－－
１４
ｉｎｐｕｔ １４，ｓｅｌｅｃｔ １２ｔｐ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｅｒｒｏｒ Ｌ２ＴＰ ｅｒｒｏｒ
（０１）ｅｖｅｎｔ Ｌ２ＴＰ ｅｖｅｎｔ
（０２）ｐａｃｋｅｔｓ Ｌ２ＴＰ ｐａｃｋｅｔｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２）： １
Ｉｎｐｕｔ １，ｓｅｌｅｃｔ ｅｖｅｎｔ：
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
