Command Line Interface Reference Manual
14
2. Configure System Monitor Status
The following message will be displayed when switch on the Router (take DI-1750 for example):
D-Link Internetwork Operating System Software
1750 Series Software, Version 1.3.1D (FULL), RELEASE SOFTWARE
Copyright (c) 2002 D-Link Corporation.
Compiled: 2003-6-5 10:50:53 by HYZHU, Image text-base: 0x6004
ROM: System Bootstrap, Version 0.2.3
Serial num:D301131000040, ID num:002430
System image file is "0605.bin"
Ｐｌｅａｓｅ ｗａｉｔ ｓｙｓｔｅｍ ｃｈｅｃｋ ｒａｍ．．．．．．
At this time, please type in“ａａａ”to enter the System Monitor Status. The following display
Ｃｈｅｃｋ ｒａｍ ＯＫ
Welcome to D-Link Multi-Protocol 1700 Router
ｍｏｎｉｔｏｒ＃
Indicates the successful entry to the System Monitor Status.
Ｎｏｔｉｃｅ：
Ｓｉｎｃｅ ｔｈｅ Ｓｙｓｔｅｍ Ｍｏｎｉｔｏｒ Ｓｔａｔｕｓ ｉｓ ｗｉｔｈ ｔｈｅ ｈｉｇｈｅｓｔ ａｕｔｈｏｒｉｔｙ， ｔｈｅ ｉｎｃｏｒｒｅｃｔ ｏｐｅｒａｔｉｏｎ ｍａｙ ｃａｕｓｅ ｓｙｓｔｅｍ
Ｂｒｅａｋｄｏｗｎ． Ｔｈｅｒｅｆｏｒｅ， ｏｎｌｙ ｔｈｅ ｔｅｒｍｉｎａｌ ｃｏｎｎｅｃｔｅｄ ｔｏ ｔｈｅ ｃｏｎｓｏｌｅ ｐｏｒｔ ｉｓ ａｌｌｏｗｅｄ ｔｏ ｅｎｔｅｒ ｔｈｉｓ ｓｔａｔｕｓ．
The user can handle the following tasks under the system monitor status:
1． Management of file system, including add and delete a file. Since the router software and configuration is saved
as file forms, the user can update or delete the software and the configuration.
2． Configure Ethernet IP addresses.
3． Test the network connection by PING test.
4． Start from a file manually.
The following is usage of the commands in detail under the system monitor status.
２．１ Ｆｉｌｅ Ｓｙｓｔｅｍ Ｃｏｍｍａｎｄｓ
There are only as most as 20 characters in a FLASH file name, and not case-sensitive.
２．２ Ｆｉｌｅ Ｓｙｓｔｅｍ Ｃｏｍｍａｎｄ
The boldface parts of all commands are the key words, the others are parameters. The parts inside the [] are optional
settings.
u Format
Format the file system and delete all data.
u dir [file name]
Display the file name and directory. The file name in [ ] displays a file that begins with certain letters. The displayed
form is as follows:
Index number file name <FILE> file length creation time
u delete filename
Delete a file. It will be prompted if the file to be deleted does not exist.
２．２．１ Ｕｐｄａｔｅ Ｓｏｆｔｗａｒｅ
This command is used to download the router system software from local or remote sites, for the version update or
customized version with special functions (eg. data encryption).
There are two methods to update the software in the monitor status.
A． By TFTP Protocol
ｍｏｎｉｔｏｒ＃ｃｏｐｙ ｔｆｔｐ＜：ｆｉｌｅｎａｍｅ＞ ｆｌａｓｈ ＜：ｆｉｌｅｎａｍｅ＞ ［ｉｐ＿ａｄｄｒ］
This command is used to copy the file from tftp server to system flash memory. The system will prompt user to input the
