Command Line Interface Reference Manual
360
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）Ａ．Ｂ．Ｃ．Ｄ ＩＰ ａｄｄｒｅｓｓ ｏｆ ｐｅｅｒ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ＩＰ Ａｄｄｒｅｓｓ：１０．０．０．１ （Ｉｎｐｕｔ ｐｅｅｒ ｉｐ Ａｄｄｒｅｓｓ）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
……
（１６）ｓｅｔ Ｓｅｔ ｖａｌｕｅｓ ｆｏｒ ｅｎｃｒｙｐｔｉｏｎ／ｄｅｃｒｙｐｔｉｏｎ
（１７）ｓｈｏｗ ｓｈｏｗ ｃｏｎｆｉｇｕｒａｔｉｏｎ ａｎｄ ｓｔａｔｕｓ
……
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１９）： １６
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ｐｅｅｒ Ａｌｌｏｗｅｄ Ｅｎｃｒｙｐｔｉｏｎ／Ｄｅｃｒｙｐｔｉｏｎ ｐｅｅｒ．
（０１）ｓｅｃｕｒｉｔｙ－ａｓｓｏｃｉａｔｉｏｎ Ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ ｐａｒａｍｅｔｅｒｓ
（０２）ｔｒａｎｓｆｏｒｍ－ｓｅｔ Ｓｐｅｃｉｆｙ ｌｉｓｔ ｏｆ ｔｒａｎｓｆｏｒｍ ｓｅｔｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２）： １
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｉｎｂｏｕｎｄ Ｉｎｂｏｕｎｄ ｍａｎｕａｌ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
（０１）ｏｕｔｂｏｕｎｄ Ｏｕｔｂｏｕｎｄ ｍａｎｕａｌ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ａｈ ＡＨ ｋｅｙ
（０１）ｅｓｐ ＥＳＰ ｋｅｙ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜２５６－４２９４９６７２９５＞ ＳＰＩ ｆｏｒ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：１００００ （Ｉｎｐｕｔ ＳＰＩ Ｖａｌｕｅ）
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ＷＯＲＤ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ ｋｅｙ ｖａｌｕｅ （ｈｅｘ ｗ／ｏ ｌｅａｄｉｎｇ ０ｘ）
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：１２３４５６ （Ｉｎｐｕｔ ａｓｓｏｃｉａｔｉｏｎ ｋｅｙ ｖａｌｕｅ）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
……
（１６）ｓｅｔ Ｓｅｔ ｖａｌｕｅｓ ｆｏｒ ｅｎｃｒｙｐｔｉｏｎ／ｄｅｃｒｙｐｔｉｏｎ
（１７）ｓｈｏｗ ｓｈｏｗ ｃｏｎｆｉｇｕｒａｔｉｏｎ ａｎｄ ｓｔａｔｕｓ
……
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１９）： １６
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
