Command Line Interface Reference Manual
252
ｎｅｉｇｈｂｏｒ １０．０．１．５ ｃｏｓｔ １５
The following example is the configuration for the router on the other side:
ｉｎｔｅｒｆａｃｅ Ｓｅｒｉａｌ１／２
ｉｐ ａｄｄｒｅｓｓ １０．０．１．３ ２５５．２５５．２５５．０
ｅｎｃａｐｓｕｌａｔｉｏｎ ｆｒａｍｅ－ｒｅｌａｙ
ｉｐ ｏｓｐｆ ｎｅｔｗｏｒｋ ｐｏｉｎｔ－ｔｏ－ｍｕｌｔｉｐｏｉｎｔ ｎｏｎ－ｂｒｏａｄｃａｓｔ
ｎｏ ｉｐ ｍｒｏｕｔｅ－ｃａｃｈｅ
ｎｏ ｋｅｅｐａｌｉｖｅ
ｎｏ ｆａｉｒ－ｑｕｅｕｅ
ｆｒａｍｅ－ｒｅｌａｙ ｌｏｃａｌ－ｄｌｃｉ ３０１
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １０．０．１．１ ｐｖｃ ３００
ｎｏ ｓｈｕｔ
！
ｒｏｕｔｅｒ ｏｓｐｆ １
ｎｅｔｗｏｒｋ １０．０．１．０ ０．０．０．２５５ ａｒｅａ ０
Variable-Length Subnet Masks Example
OSPF, static routes, and IS-IS support variable-length subnet masks (VLSMs). With VLSMs, you can use different masks
for the same network number on different interfaces, which allows you to conserve IP addresses and more efficiently use
available address space.
In the following example, a 30-bit subnet mask is used, leaving two bits of address space reserved for serial line host
addresses. There is sufficient host address space for two host endpoints on a point-to-point serial link.
ｉｎｔｅｒｆａｃｅ ｅｔｈｅｒｎｅｔ １／０
ｉｐ ａｄｄｒｅｓｓ １３１．１０７．１．１ ２５５．２５５．２５５．０
！ ８ ｂｉｔｓ ｏｆ ｈｏｓｔ ａｄｄｒｅｓｓ ｓｐａｃｅ ｒｅｓｅｒｖｅｄ ｆｏｒ ｅｔｈｅｒｎｅｔｓ
ｉｎｔｅｒｆａｃｅ ｓｅｒｉａｌ １／１
ｉｐ ａｄｄｒｅｓｓ １３１．１０７．２５４．１ ２５５．２５５．２５５．２５２
！ ２ ｂｉｔｓ ｏｆ ａｄｄｒｅｓｓ ｓｐａｃｅ ｒｅｓｅｒｖｅｄ ｆｏｒ ｓｅｒｉａｌ ｌｉｎｅｓ
！ Ｒｏｕｔｅｒ ｉｓ ｃｏｎｆｉｇｕｒｅｄ ｆｏｒ ＯＳＰＦ ａｎｄ ａｓｓｉｇｎｅｄ ＡＳ １０７
ｒｏｕｔｅｒ ｏｓｐｆ １０７
！ Ｓｐｅｃｉｆｉｅｓ ｎｅｔｗｏｒｋ ｄｉｒｅｃｔｌｙ ｃｏｎｎｅｃｔｅｄ ｔｏ ｔｈｅ ｒｏｕｔｅｒ
ｎｅｔｗｏｒｋ １３１．１０７．０．０ ０．０．２５５．２５５ ａｒｅａ ０．０．０．０
OSPF Routing and Route Redistribution Examples
OSPF Routing and Route Redistribution Examples
OSPF typically requires coordination among many internal routers, area border routers, and autonomous system boundary
routers. At a minimum, OSPF-based routers can be configured with all default parameter values, with no authentication,
and with interfaces assigned to areas.
Three examples follow:
1. The first is a simple configuration illustrating basic OSPF commands.
2. The second example illustrates a configuration for an internal router, ABR, and ASBRs within a single, arbitrarily
assigned, OSPF autonomous system.
3. The third example illustrates a more complex configuration and the application of various tools available for
controlling OSPF-based routing environments.
Basic OSPF Configuration Example
