Command Line Interface Reference Manual
144
Will you excute it? (Y/N):y
……
(08)pap Set PAP authentication parameters
(09)timeout Set PPP timeout parameters
Please Input the code of command to be excute(0-9): 8
(00)refuse Refuse to authenticate using PAP
(01)sent-username Set outbound PAP username and password
Please Input the code of command to be excute(0-1): 1
(00)WORD Set outbound PAP username and password
Please Input the code of command to be excute(0-0): 0
Please input a string:router （input username）
(00)WORD Outbound PAP password
Please Input the code of command to be excute(0-0): 0
Please input a string:mypassword （input password）
Will you excute it? (Y/N):y
！configuring the Dialer Map to the center ISDN PRI
Key Word:
U(undo) D(default) Q(quit)
……
(10)dialer Dial-on-demand routing (DDR) commands
(11)dialer-group Assign interface to dialer-list
……
Please Input the code of command to be excute(0-32): 10
Key Word:
U(undo) D(default) Q(quit)
……
(07)map Define multiple dial-on-demand numbers
(08)remote-name Specify remote name
……
Please Input the code of command to be excute(0-11): 7
(00)A.B.C.D IP address
Please Input the code of command to be excute(0-0): 0
Please input a IP Address:10.0.0.100 （input ip address）
(00)WORD Dialer string
(01)broadcast Broadcast to this address
……
Please Input the code of command to be excute(0-5): 0
Please input a string:12345678 （input dial-string）
Will you excute it? (Y/N):y
！configuring the static route to the center ISDN PRI
Key Word:
U(undo) D(default) Q(quit)
……
(14)exit exit / quit
(15)fair-queue enable fair queue on interface
……
Please Input the code of command to be excute(0-32): 14
Will you excute it? (Y/N):y
[DEFAULT@Router /config/]#ip
