Command Line Interface Reference Manual
483
(01)<cr>
Please Input the code of command to be excute(0-1): 0
Input 0
Key Word:
Q(quit)
(00)FastEthernet FastEthernet interface
(01)Ethernet Ethernet interface
(02)Serial Serial interface
(03)Async Asynchronous interface
(04)Null Null interface
Please Input the code of command to be excute(0-4): 0
Input 0，display the llc2 status of interface f0/0
Please input a interface name:f0/0
Will you excute it? (Y/N):y
Input y，display the information below：
FastEthernet0/0: DOWN
ack-time = 12 s, ack-delay-time = 400 ms, idle-time = 12 s
pf-time = 12 s, busy-time = 12 s, rej-time = 12 s, N2 = 12
IFRAMEs 0/0, TESTs 0/0, XIDs 0/0, UIs 0/0
FRMRs 0/0, RRs 0/0 RNRs 0/0, REJs 0/0
SABMEs 0/0, UAs 0/0, DISCs 0/0, DMs 0/0
Discard:0, N(s) err:0, N(r) err:0, Total 0/0
no LLC2 Connections
10.2.11 Debug the LLC2 link information
Command Purpose
ｄｅｂｕｇ ｌｌｃ２ ［ｐａｃｋｅｔ］［ｅｒｒｏｒ］［ｓｔａｔｅ］
This command is mainly used to enable the LLC2 debug.
“packet” means enabling the LLC2 data information debugging error，
“error” means enabling the LLC2 error information debugging
“state” means enabling the LLC2 status information debugging.
Select IIc2 command from management list.
Key Word:
Q(quit)
(00)errors LLC2 error information
(01)packets LLC2 I/O packets
(02)state LLC2 state information
(03)<cr>
Please Input the code of command to be excute(0-3):
Input 0，selecting error parameter
Input 1，selecting packet parameter
Input 2，selecting state parameter
Example of LLC2 configuration
