DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
182
Green option.
Drop Rate Low
Specify the low drop rate value used.
Drop Rate High
Specify the high drop rate value used.
Click the Apply button to accept the changes made for each individual section.
SRED Drop Counter
This window is used to view the SRED Drop Counter settings on the Switch.
To view the following window, click QoS > SRED > SRED Drop Counter as shown below.
Figure 6-16 SRED Drop Counter Window
The following parameters can be configured:
Parameter Description
Unit
Select the unit you want to configure.
