DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

383

Figure 12-16 Download Configuration File from HTTP window

The fields that can be configured are described below:

Parameter Description

Unit

Use the drop-down menu to select a unit for receiving the configuration file. Select All

for all units.

Source File

Enter the location and name of the Source File, or click the Browse button to

navigate to the configuration file for the download.

Destination File

Enter the location and name of the Destination File.

Increment

Tick the check box to keep the existing configuration before applying to the new

configuration. Deselect the check box to clear the existing configuration before

applying to the new configuration.

Click Download to initiate the download.

Upload Configuration

The following window is used to upload the configuration file from the Switch.

To TFTP

This window allows the user to upload the configuration file from the Switch to a TFTP Server.

To view this window, click Tools > Upload Configuration > To TFTP, as shown below:

Figure 12-17 Upload Configuration File to TFTP window

The fields that can be configured are described below:

Parameter Description

Unit

Use the drop-down menu to select a unit for uploading the configuration file.

TFTP Server IP

Enter the TFTP server IP address used.

IPv4

Click the radio button to enter the TFTP server IP address used.

IPv6

Click the radio button to enter the TFTP server IPv6 address used.

Domain Name

Click the radio button to enter the TFTP server domain name used.
