D-Link DGS-3000-28SC [51/444] Management settings

DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

Managed Flag

Use the drop-down menu to enable or disable managed flag. When enabled, this

option specifies that hosts receiving the RA message should use the stateful auto-

configuration mechanism to get IPv6 addresses for their interface.

Other Configuration

Flag

Use the drop-down menu to enable or disable other configuration flag. When

enabled, this option specifies that hosts receving the RA message should also

obtain information other than the addresses obtained using the stateful auto-

configuration.

Min Router AdvInterval

(3-1350)

Enter the minimum interval of sending unsolicited multicast router advertisements

from the interface.

Max Router AdvInterval

(4-1800)

Enter the maximum interval of sending unsolicited multicast router advertisements

from the interface.

Click the Apply button to accept the changes made for each individual section.

Click the <<Back button to discard the changes made and return to the previous page.

Click the View All IPv6 Address link to view all the current IPv6 address.

Click the View All IPv6 Address link to see the following window.

Figure 3-12 IPv6 Interface Settings window

Click the <<Back button to return to the previous page.

Management Settings

Users can stop the scrolling of multiple pages beyond the limits of the console when using the Command Line

Interface.

This window is also used to enable the DHCP auto configuration feature on the Switch. When enabled, the Switch

is instructed to receive a configuration file from a TFTP server, which will set the Switch to become a DHCP client

automatically on boot-up. To employ this method, the DHCP server must be set up to deliver the TFTP server IP

address and configuration file name information in the DHCP reply packet. The TFTP server must be up and

running and hold the necessary configuration file stored in its base directory when the request is received from the

Switch. For more information about loading a configuration file for use by a client, see the DHCP server and/or

TFTP server software instructions. The user may also consult the Upload Log File window description located in

the Tools section of this manual.

If the Switch is unable to complete the DHCP auto configuration, the previously saved configuration file present in

the Switch’s memory will be used.

Users can also configure Password Encryption on the Switch.

To view the following window, click Management > Management Settings, as show below:
