DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
392
unitID: The unit ID.
portNum: The port number.
vid: The VLAN ID on which the host exists.
Event description: A host has aged out.
Log Message: MAC-based Access Control host aged out (MAC: <macaddr>, port:
<[unitID]portNum>, VID: <vid>)
Parameters description:
macaddr: The MAC address
unitID: The unit ID.
portNum: The port number.
vid: The VLAN ID on which the host exists.
Informational
DHCPv6 client
Event description: DHCPv6 client interface administrator state changed.
Log Message: DHCPv6 client on interface <ipif-name> changed state to [enabled |
disabled].
Parameters description:
<ipif-name>: Name of the DHCPv6 client interface.
Informational
Event description: DHCPv6 client obtains an ipv6 address from a DHCPv6 server.
Log Message: DHCPv6 client obtains an ipv6 address < ipv6address > on interface
<ipif-name>.
Parameters description:
ipv6address: ipv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event description: The ipv6 address obtained from a DHCPv6 server starts renewing.
Log Message: The IPv6 address < ipv6address > on interface <ipif-name> starts
renewing.
Parameters description:
ipv6address: ipv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event description: The ipv6 address obtained from a DHCPv6 server renews success.
Log Message: The IPv6 address < ipv6address > on interface <ipif-name> renews
success.
Parameters description:
ipv6address: ipv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event description: The ipv6 address obtained from a DHCPv6 server starts rebinding
Log Message: The IPv6 address < ipv6address > on interface <ipif-name> starts
rebinding.
Parameters description:
ipv6address: ipv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event description: The ipv6 address obtained from a DHCPv6 server rebinds success
Log Message: The IPv6 address < ipv6address > on interface <ipif-name> rebinds
success.
Informational
