DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
20
Figure 2-16 EEE Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to be configured.
From Port / To Port
Select the appropriate port range used for the configuration here.
State
Select to enable or disable the state of this feature here.
Click the Apply button to implement changes made.
NOTE: EEE and ERPS are mutually exclusive functions.
Serial Port Settings
This window allows the user to adjust the Baud Rate and the Auto Logout values.
To view the following window, click System Configuration > Serial Port Settings, as show below:
Figure 2-17 Serial Port Settings window
The fields that can be configured or displayed are described below:
