DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
359
Parameter Description
Unit
Select the unit you to be displayed.
Port
Use the drop-down menu to choose the port that will display statistics.
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The
default value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value
is 200.
CRCError
Select to display received FCS error frame counter information.
UnderSize
Select to display received undersize frame counter information.
OverSize
Select to display received oversize frame counter information.
Fragment
Select to display received fragment counter information.
Jabber
Select to display received jabber frame counter information.
SymbolErr
Select to display received code error counter information.
BuffFullDr
Counts for each packet that is discarded when input buffer is full.
ACLDr
Counts for each packet that is denied by ACLs.
MulticastDR
Counts for each multicast packet that is discarded.
VLANIngDR
Counts for each packet that is discarded by VLAN ingress checking.
InvalidIPv6
Counts for IPv6 L3 discard.
STPDr
Counts for packets dropped when ingress port is not in forwarding state.
StoFDBDis
Counts for receive policy discard.
MTUDr
Counts for frames received that exceed maximum frame in length and contain a valid
or invalid FCS.
Show/Hide
Select the check boxes to display the errors.
Click the Apply button to accept the changes made for each individual section.
Click the Clear button to clear all statistics counters on this window.
Click the View Table link to display the information in a table rather than a line graph.
Click the View Graphic link to display the information in a line graph rather than a table.
Transmitted (TX)
To select a port to view these statistics for, select the port by using the Port drop-down menu. The user may also
use the real-time graphic of the Switch at the top of the web page by simply clicking on a port.
To view the following window, click Monitoring > Statistics > Port Statistics > Errors > Transmitted (TX) as
shown below.
