DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

251

Figure 8-22 Authentication RADIUS Server Settings window

The fields that can be configured are described below:

Parameter Description

Index

Choose the desired RADIUS server to configure: 1, 2 or 3.

IPv4 Address

Click the radio button and enter the RADIUS server IP address.

IPv6 Address

Click the radio button and enter the RADIUS server IPv6 address.

Authentication Port (1-

65535)

Set the RADIUS authentic server(s) UDP port which is used to transmit

RADIUS data between the Switch and the RADIUS server. The default port is

1812.

Accounting Port (1-65535)

Set the RADIUS account server(s) UDP port which is used to transmit RADIUS

accounting statistics between the Switch and the RADIUS server. The default

port is 1813.

Timeout (1-255)

Set the RADIUS server age-out, in seconds.

Retransmit (1-20)

Set the RADIUS server retransmit time, in times.

Key

Set the key the same as that of the RADIUS server.

Confirm Key

Confirm the key the same as that of the RADIUS server.

Click the Apply button to accept the changes made.

Click the Edit button to configure the specified entry.

Click the Delete button to remove the specified entry.

RADIUS Authentication

Users can display information concerning the activity of the RADIUS authentication client on the client side of the

RADIUS authentication protocol.

To view the following window, click Security > RADIUS > RADIUS Authentication as shown below.
