DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
431
Binding objects:
1:swPowerUnitIndex
2:swPowerID
3:swPowerStatus
2.2.0.1
swPowerFailure
Power Failure notification.
Binding objects:
1:swPowerUnitIndex
2:swPowerID
3:swPowerStatus
1.3.6.1.4.1.171.12.11.2.
2.2.0.2
swPowerRecover
Power Recover notification.
Binding objects:
1:swPowerUnitIndex
2:swPowerID
3:swPowerStatus
1.3.6.1.4.1.171.12.11.2.
2.2.0.3
