DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

340

Figure 10-12 CFM Port Settings window

The fields that can be configured are described below:

Parameter Description

Unit

Select the unit you want to configure.

From Port / To Port

Use the drop-down menus to select a range of ports to be configuration.

State

Use the drop-down menu to enable or disable the state of specific port regarding the

CFM configuration.

Click the Apply button to accept the changes made.

CFM MIPCCM Table

This window is used to show the MIP CCM database entries.

To view the following window, click OAM > CFM > CFM MIPCCM Table as shown below.

Figure 10-13 CFM MIPCCM Table window

CFM Loopback Settings

This window is used to start a CFM loopback test.

To view the following window, click OAM > CFM > CFM Loopback Settings as shown below.
