DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

Figure 2-15 Jumbo Frame Settings window

The fields that can be configured are described below:

Parameter Description

Jumbo Frame

Use the radio buttons to enable or disable the Jumbo Frame function on the Switch.

The default is Disabled. When disabled, the maximum frame size is 1536 bytes.

When enabled, the maximum frame size is 13312 bytes.

Unit

Select the unit to be configured.

From Port / To Port

Select the appropriate port range used for the configuration here.

State

Select to enable or disable the Jumbo Frame state for the specified ports.

Click the Apply button to accept the changes made for each individual section.

EEE Settings

Energy Efficient Ethernet (EEE) is defined in IEEE 802.3az. It is designed to reduce the energy consumption of a

link when no packets are being sent.

To view the following window, click System Configuration > Port Configuration > EEE Settings, as shown

below.
