DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
428
(1) dot1agCfmMdIndex
(2) dot1agCfmMaIndex
(3) dot1agCfmMepIdentifier
swCFMExtAISCleared
A notification is generated when
local MEP
exits AIS status.
Binding objects:
(1) dot1agCfmMdIndex
(2) dot1agCfmMaIndex
(3) dot1agCfmMepIdentifier
1.3.6.1.4.1.171.12.86.10
0.0.2
swCFMExtLockOccurred
A notification is generated when local MEP
enters lock status.
Binding objects:
(1) dot1agCfmMdIndex
(2) dot1agCfmMaIndex
(3) dot1agCfmMepIdentifier
1.3.6.1.4.1.171.12.86.10
0.0.3
swCFMExtLockCleared
A notification is generated when local MEP
exits lock status.
Binding objects:
(1) dot1agCfmMdIndex
(2) dot1agCfmMaIndex
(3) dot1agCfmMepIdentifier
1.3.6.1.4.1.171.12.86.10
0.0.4
Port
linkUp
A notification is generated when port
linkup.
Binding objects:
(1) ifIndex,
(2) if AdminStatus
(3) ifOperStatu
1.3.6.1.6.3.1.1.5.4
linkDown
A notification is generated when port
linkdown.
Binding objects:
(1) ifIndex,
(2) if AdminStatus
(3) ifOperStatu
1.3.6.1.6.3.1.1.5.3
DDM swDdmAlarmTrap
The trap is sent when any parameter value
exceeds the alarm threshold value or
recovers to normal status depending on
the configuration of the trap action.
Binding objects:
(1) swDdmPort
(2) swDdmThresholdType
(3) swDdmThresholdExceedType
(4) swDdmThresholdExceedOrRecover
1.3.6.1.4.1.171.12.72.4.
0.1
swDdmWarningTrap
The trap is sent when any parameter value
exceeds the warning threshold value or
recovers to normal status depending on
the configuration of the trap action.
Binding objects:
(1) swDdmPort
(2) swDdmThresholdType
(3) swDdmThresholdExceedType
(4) swDdmThresholdExceedOrRecover
1.3.6.1.4.1.171.12.72.4.
0.2
DOS Attack
Prevention
swDoSAttackDetected
This trap is sent when the specific DoS
packet is received and trap is enabled.
Binding objects:
1.3.6.1.4.1.171.12.59.4.
0.1
