DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide

Figure 2-6 DDM Bias Current Threshold Settings window

The fields that can be configured are described below:

Parameter Description

Unit

Select the unit to be configured.

From Port / To Port

Select a range of ports to be configured.

High Alarm (0-131)

This is the highest threshold for the alarm. When the operating parameter rises above

this value, action associated with the alarm will be taken.

Low Alarm (0-131)

This is the lowest threshold for the alarm. When the operating parameter falls below

this value, action associated with the alarm will be taken.

High Warning (0-131)

This is the highest threshold for the warning. When the operating parameter rises

above this value, action associated with the warning will be taken.

Low Warning (0-131)

This is the lowest threshold for the warning. When the operating parameter falls

below this value, action associated with the warning will be taken.

Click the Apply button to accept the changes made.

DDM TX Power Threshold Settings

This window is used to configure the threshold of Tx power for specific ports on the Switch.

To view the following window, click System Configuration > Port Configuration > DDM > DDM TX Power

Threshold Settings, as show below:
