DGS-3000-28SC Layer 2 Managed Stackable Gigabit Switch Web UI Reference Guide
417
Parameters description:
unitID: The unit ID.
portNum: The port number.
thresholdType: the DDM threshold type. The value should be one of the following
values: temperature, supply voltage, bias current, TX power, RX power.
Event description: DDM exceeded DDM alarm threshold
Log Message: Port <[unitID:]portNum> optic module [thresholdType] exceeded the
[thresholdSubType] alarm threshold
Parameters description:
unitID: The unit ID.
portNum: The port number.
thresholdType: the DDM threshold type. The value should be one of the following
values: temperature, supply voltage, bias current, TX power, RX power.
thesholdSubType: the DDM threshold sub type, the value should be “high” or “low”.
warning
Event description: DDM exceeded DDM warning threshold
Log Message: Port <[unitID:]portNum> optic module [thresholdType] exceeded the
[thresholdSubType] warning threshold
Parameters description:
unitID: The unit ID.
portNum: The port number.
thresholdType: the DDM threshold type. The value should be one of the following
values: temperature, supply voltage, bias current, TX power, RX power.
thesholdSubType: the DDM threshold sub type, the value should be “high” or “low”.
warning
BPDU Attack
Protection
Event description: BPDU attack happened.
Log Message: Port<[unitID:]portNu
m> enter BPDU under protection state (mode: drop /
block / shutdown)
Parameters description:
unitID: The unit ID.
portNum: The port number.
mode:The BPDU currnt state
Informational
Event description: BPDU attack automatically recover.
Log Message: Port <[unitID:]portNum> recover from BPDU under protection state
automatically
Parameters description:
unitID: The unit ID.
portNum: The port number.
Informational
Event description: BPDU attack manually recover.
Log Message: Port<[unitID:]portNum> recover from BPDU under protection state
automatically
Parameters description:
unitID: The unit ID.
portNum: The port number.
Informational
SSH
Event description: Successfully download client public keys. Informational
