DGS-6600 Series Switch m configure terminal
CLI Reference Guide
135
configure terminal
Use this command to enter the global configuration mode.
configure terminal
Syntax None.
Default None.
Command Mode Privileged EXEC.
Usage Guideline Entering into the configuration mode allows configuration settings of the switch to
be entered or modified i.e. performing switch configuration.
Example This example shows how to enter into the configuration mode:
Switch#configure terminal
Switch(config)#
