Power Modules
3.1 Power Modules Blocksize (PM340)
Manual
102 Manual, 01/2011, 6SL3097-4AC10-0BP2
3.1.7.3 Current derating depending on the pulse frequency
Interrelationship between the pulse frequency and current de-rating
Table 3- 14 Current de-rating depending on the pulse frequency
Order
No.
Line
supply
voltage
Rated
current
Power
(low
overload)
Output current in A at a pulse frequency of:
6SL3210 A [kW] 4 kHz 6 kHz
85%
8 kHz
70 %
10 kHz
60%
12 kHz
50 %
14 kHz
45%
16 kHz
40 %
FSA
1SB11-
0UA0
0.9 0.12 0.9 0.76 0.63 0.54 0.45 0.40 0.36
1SB12-
3UA0
2.3 0.37 2.3 1.96 1.61 1.38 1.15 1.03 0.92
1SB14-
0UA0
1-ph.
230 V
AC
3.9 0.75 3.9 3.31 2.73 2.34 1.95 1.75 1.56
FSA
1SE11-
3UA0
1.3 0.37 1.3 1.10 0.91 1.78 0.65 0.58 0.52
1SE11-
7UA0
1.7 0.55 1.7 1.44 1.19 1.02 0.85 0.76 0.68
1SE12-
2UA0
2.2 0.75 2.2 1.87 1.54 1.32 1.1 0.99 0.88
1SE13-
1UA0
3.1 1.1 3.1 2.63 2.17 1.86 1.55 1.39 1.24
1SE14-
1UA0
4.1 1.5 4.1 3.48 2.87 2.46 2.05 1.84 1.64
FSB
1SE16-
0UA0
5.9 2.2 5.9 5.01 4.13 3.54 2.95 2.65 2.36
1SE17-
7UA0
7.7 3 7.7 6.54 5.39 4.62 3.85 3.46 3.08
1SE21-
0UA0
10.2 4 10.2 8.67 7.14 6.12 5.1 4.59 4.08
FSC
1SE21-
8UA0
18 5.5 18 15.3 12.6 10.8 9 8.1 7.2
1SE22-
5UA0
25 7.5 25 21.25 17.5 15 12.5 11.25 10
1SE23-
2UA0
32 15 32 27.2 22.4 19.2 16 14.4 12.8
FSD
1SE23-
8UA0
3-ph.
400 V
AC
38 18.5 38 32.3 26.6 22.8 19 17.1 15.2
