Cabinet design and EMC for components, Blocksize format
9.8 Notes on electrical cabinet cooling
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
271
9.8.3.4 Power loss for Power Modules
Table 9- 12 Overview of power loss during rated operation for Power Modules
Rated output current I
rated
/Unit rating based on
I
rated
Frame size Line supply voltage Unit Power loss
Blocksize PM340
0.9 A/0.12 kW FSA 1-ph. 200 to 240 V AC W 60
2.3 A/0.37 kW FSA 1-ph. 200 to 240 V AC W 75
3.9 A/0.75 kW FSA 1-ph. 200 to 240 V AC W 110
1.3 A/0.37 kW FSA 3-ph. 380 to 480 V AC W 100
1.7 A/0.55 kW FSA 3-ph. 380 to 480 V AC W 100
2.2 A/0.75 kW FSA 3-ph. 380 to 480 V AC W 100
3.1 A/1.1 kW FSA 3-ph. 380 to 480 V AC W 110
4.1 A/1.5 kW FSA 3-ph. 380 to 480 V AC W 110
5.9 A/2.2 kW FSB 3-ph. 380 to 480 V AC W 140
7.7 A/3 kW FSB 3-ph. 380 to 480 V AC W 160
10.2 A/4 kW FSB 3-ph. 380 to 480 V AC W 180
18 A/7.5 kW FSC 3-ph. 380 to 480 V AC W 240
25 A/11 kW FSC 3-ph. 380 to 480 V AC W 300
32 A/15 kW FSC 3-ph. 380 to 480 V AC W 400
38 A/18.5 kW FSD 3-ph. 380 to 480 V AC W 380
45 A/22 kW FSD 3-ph. 380 to 480 V AC W 510
60 A/30 kW FSD 3-ph. 380 to 480 V AC W 690
75 A/37 kW FSE 3-ph. 380 to 480 V AC W 990
90 A/45 kW FSE 3-ph. 380 to 480 V AC W 1210
110 A/55 kW FSF 3-ph. 380 to 480 V AC W 1420
145 A/75 kW FSF 3-ph. 380 to 480 V AC W 1930
178 A/90 kW FSF 3-ph. 380 to 480 V AC W 2310
Blocksize Liquid Cooled PM340
38 A/18.5 kW FSD 3-ph. 380 to 480 V AC W 90
1)
60 A/30 kW FSD 3-ph. 380 to 480 V AC W 130
1)
75 A/37 kW FSE 3-ph. 380 to 480 V AC W 160
1)
90 A/45 kW FSE 3-ph. 380 to 480 V AC W 190
1)
110 A/55 kW FSF 3-ph. 380 to 480 V AC W 210
1)
178 A/90 kW FSF 3-ph. 380 to 480 V AC W 350
1)
1) Power loss to ambient air
