Siemens 6SL3210-1SB11-0UA0 [206/318] Technical data
![Siemens 6SL3210-1SE31-0AA0 [206/318] Technical data](/views2/1587218/page206/bgce.png)
Supplementary system components and encoder system integration
7.3 Sensor Module Cabinet-Mounted SMC20
Manual
206 Manual, 01/2011, 6SL3097-4AC10-0BP2
7.3.7 Technical data
Table 7- 13 Technical data
6SL3055-0AA00-5BAx Unit Value
Electronics power supply
Voltage
Current (without encoder system)
Current (with encoder system)
Power loss
V
DC
A
DC
A
DC
W
24 DC (20.4 – 28.8)
≤ 0.20
≤ 0.35
≤ 10
Encoder system power supply
Voltage
Current
V
encoder
A
encoder
5 V DC (with Remote Sense)
1)
0.35
Encoder frequency that can be evaluated
(f
encoder
)
kHz ≤ 500
SSI baud rate
2)
kHz 100 (6SL3055-0AA00-5BA2)
100 - 250 (6SL3055-0AA00-5BA3)
Max. encoder cable length m 100
PE/ground connection On housing with M4/1.8 Nm screw
Weight kg 0.45
Degree of protection IP20 or IPXXB
1) A controller compares the encoder system supply voltage - sensed via the Remote Sense cables - with the reference
supply voltage of the encoder system, and adjusts the supply voltage for the encoder system at the output of the drive
module until the required supply voltage is obtained directly at the encoder system (only for 5 V encoder system power
supply).
2) Only possible for SSI encoders with 5 V supply
NOTICE
Current controller clock cycle
When a current controller clock cycle of 31.25 µs is used, a SMC20 with MLFB 6SL3055-
0AA00-5BA3 must be used.
