Cabinet design and EMC for components, Blocksize format
9.6 Arrangement of components and equipment
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
263
Mounting Power Modules with sub-chassis components
A large number of system components are designed as sub-chassis components for PM340
Power Modules with frame sizes FSA to FSE. In such cases, the sub-chassis components
are mounted on the mounting surface, with the PM340 Power Module mounted in front in
order to save space.
Table 9- 6 Available sub-chassis components
FSA FSB FSC FSD FSE
Line filter x - - - -
Line reactor x x x x x
Braking resistor x x
Motor reactor x x x
x = can be used as a sub-chassis component
-.. not available as an external component (use a Power Module with an integrated line filter)
Up to two sub-chassis components can be mounted in front of one another. For
configurations involving more than two sub-chassis-type components (e.g. line reactor +
motor reactor + braking resistor), individual components must be mounted to the side of the
Power Module.
The following mounting sequence applies to frame sizes FSA to FSC:
Table 9- 7 Mounting sequence for sub-chassis components, starting from the cabinet wall
Frame size Mounting sequence
Without an external line filter:
Motor reactor - line reactor - PM340
FSA
With external line filter:
Line reactor - line filter - PM340 or
motor reactor - line filter - PM340
FSB Motor reactor - line reactor - PM340
FSC Motor reactor - line reactor - PM340
NOTICE
The braking resistor must always be mounted to the side of the Power Module, as it can get
very hot.
Wiring rules for DRIVE-CLiQ
Further information can be found in the manual:
SINAMICS S110 Function Manual Drive Functions
