Supplementary system components and encoder system integration
7.3 Sensor Module Cabinet-Mounted SMC20
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
203
Cause and rectification of faults
Further information about the causes of faults and how to remedy them may be found in the
manual: SINAMICS S120 Commissioning Manual.
7.3.4 Meaning of the LED
Table 7- 12 Meaning of LEDs on the Sensor Module Cabinet-Mounted SMC20
LED Color Status Description, cause Remedy
- Off Electronics power supply is missing or outside permissible
tolerance range.
–
Green Continuous
light
The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
–
Orange Continuous
light
DRIVE-CLiQ communication is being established. –
Red Continuous
light
At least one fault is present in this component.
Note:
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Remedy and
acknowledge fault
Flashing
0.5 Hz
Firmware is being downloaded. – Green /
red
Flashing
2 Hz
Firmware download is complete. Wait for POWER ON Carry out a POWER
ON
RDY
READY
Green /
orange
or
Red /
orange
Flashing
light
Component recognition via LED is activated (p0144).
Note:
Both options depend on the LED status when component
recognition is activated via p0144 = 1.
–
Cause and rectification of faults
The following documents contain information about the cause of faults and how they can be
rectified:
SINAMICS S120 Commissioning Manual (IH1)
SINAMICS S120/S150, List Manual (LH1)
