Supplementary system components and encoder system integration
7.1 Basic Operator Panel BOP20
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
187
BOP20 keyboard
Table 7- 2 Assignment of the BOP20 keyboard
Key Name Meaning
ON Powering-up the drives for which the command "ON/OFF1",
"OFF2" or "OFF3" should come from the BOP.
OFF Powering-down the drives for which the commands "ON/OFF1",
"OFF2" or "OFF3" should come from the BOP.
Note:
The effectiveness of these keys can be defined using the
appropriate BICO parameterization (e.g. using these keys, it is
possible to simultaneously control all of the axes that have been
configured).
The structure of the BOP control word corresponds to the structure
of the PROFIBUS control word.
Functions The meaning of these keys depends on the actual display.
Note:
The effectiveness of this key to acknowledge faults can be defined
using the appropriate BiCo parameterization.
Parameter The meaning of these keys depends on the actual display.
Raise
Lower
The keys are dependent on the actual display and are used to
raise or lower values.
