Motor-side power components
5.1 Motor reactors (blocksize)
Manual
140 Manual, 01/2011, 6SL3097-4AC10-0BP2
Table 5- 4 Total dimensions: Motor reactor, frame size FSF, all data in mm and (inches)
Motor reactor
6SE6400-
3TC14-5FD0
3TC15-4FD0
Frame size FSF FSF
b1 138 (5.43) 101 (3.97)
b2 169 (6.65) 121 (4.76)
b3 138 (5.43) 101 (3.97)
b4 264 (10.39) 200 (7.87)
e1 131 (5.15) 119 ± 2 (4.68 ± 0.07)
e2 90 (3.54) 109 ± 2 (4.29 ± 0.07)
e3 78 (3.07) -
