Motor-side power components
5.1 Motor reactors (blocksize)
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
145
Table 5- 7 Mounting dimensions of motor reactors, frame sizes FSD, FSE, all data in mm and (inches)
Motor reactor 6SE6400- 3TC05-4DD0 3TC03-8DD0 3TC07-5ED0 3TC08-0ED0
Frame size FSD FSD FSE FSE
a2 20 (0.78) 20 (0.78) 20 (0.78) 20 (0.78)
a3 4 (0.15) 4 (0.15) 4 (0.15) 4 (0.15)
a4 10 (0.39) 10 (0.39) 10 (0.39) 10 (0.39)
a5 ∅6 (0.23) ∅6 (0.23) ∅7 (0.27) ∅7
I4 225 (8.85) 225 (8.85) 270 (10.62) 225 (8.85)
I5 76 ±5 (2.99 ±0.19) 76 ±5 (2.99 ±0.19) 88 ±5 (3.46 ±0.19) 76 ±5 (2.99 ±0.19)
hmax 210 (8.26) 210 (8.26) 248 (9.76) 210 (8.26)
h2 120 ±2 (4.72 ±0.07) 120 ±2 (4.72 ±0.07) 140 ±2 (5.51 ±0.07) 120 ±2 (4.72 ±0.07)
h3 45 ±2 (1.77 ±0.07) 45 ±2 (1.77 ±0.07) 50 ±2 (1.96 ±0.07) 45 ±2 (1.77 ±0.07)
n1 70 (2.75) 94 (3.70) 101 (3.97) 70 (2.75)
n2 176 (6.88) 176 (6.88) 200 (7.87) 176 (6.88)
n3 max. 140 (5.51) max. 164 max. 187.5 (7.38) max. 140 (5.51)
n4 54 ±2 (2.12 ±0.07) 54 ±2 (2.12 ±0.07) 68.5 ±2 (2.69
±0.07)
54 ±2 (2.12 ±0.07)
d3 M6 M6 M8 M6
Motor reactor
PE M6 M6 M6 M6
Tightening
torque [Nm]
3.5-4.0 3.5-4.0 9.5-10.0
3.5-4.0
3.5-4.0
Table 5- 8 Mounting dimensions of motor reactor, frame size FSF, all data in mm and (inches)
Motor reactor 6SE6400- 3TC14-5FD0 3TC15-4FD0
Frame size FSF FSF
a2 20 (0.78) 20 (0.78)
a3 4 (0.15) 4 (0.15)
a4 10 (0.39) 10 (0.39)
a5 ∅9 (0.35) ∅9 (0.35)
I4 357 (14.05) 270 (10.62)
I5 120 ±5 (4.72 ±0.19) 88 ±5 (3.46 ±0.19)
hmax 321 (12.63) 248 (9.76)
h2 185 ±2 (7.28 ±0.07) 140 ±2 (5.51 ±0.07)
h3 60 ±2 (2.36 ±0.07) 50 ±2 (1.96 ±0.07)
n1 138 (5.43) 101 (3.97)
n2 264 (10.39) 200 (7.87)
n3 max. 220.5 (8.68) max. 187.5 (7.38)
n4 65.5 ±2 (2.57 ±0.07) 68.5 ±2 (2.69 ±0.07)
d3 M8 M8
Motor reactor
PE M8 M6
Tightening
torque [Nm]
9.5-10.0 9.5-10.0
3.5-4.0
