Mains connection and line-side power components
2.8 Line reactors
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
55
2.8.6 Technical data, Blocksize
Table 2- 10 Technical specifications, blocksize line reactors, frame size FSA
Line supply voltage 1-ph 200 V AC -10 % to 240 V AC +10%
Order No. 6SE6400- 3CC00-4AB3 3CC01-0AB3
Suitable for Power Module
6SL3210-
1SB11-0xxx
1SB12-3xxx
1SB14-0xxx
Rated line reactor current A 3.4 8.1
Power loss
50 / 60 Hz
W 12.5/15 11.5/14.5
Line supply connection L1, N 6 mm screw terminals
2
6 mm screw terminals
2
Load connection
1U2, 1V2, 1W2
Cable 3 x 1.5 mm
2
Length approx. 0.38 m
Cable 3 x 1.5 mm
2
Length approx. 0.38 m
PE connection M5 stud M5 stud
Degree of protection IP20 or IPXXB IP20 or IPXXB
Weight kg 1.3 1.3
Table 2- 11 Technical specifications, blocksize line reactors, frame size FSA
Line supply voltage 3-ph 380 V AC -10 % to 480 V AC +10 %
Order no. 6SE6400- 3CC00-2AD3 3CC00-4AD3 3CC00-6AD3
Suitable for
Power Module 6SL3210-
1SE11-3UA0
1SE11-7UA0
1SE12-2UA0
1SE13-1UA0
1SE14-1UA0
Rated line reactor current A 1.9 3.5 4.8
Power loss
50 / 60 Hz
W 6/7 12.5/15 7.5/9
Line supply connection
U1, V1, W1
Screw-type terminal 6 mm
2
Screw-type terminal 6 mm
2
Screw-type terminal 6 mm
2
Load connection
1U2, 1V2, 1W2
Cable 4 x 1.5 mm
2
Length approx. 0.38 m
Cable 4 x 1.5 mm
2
Length approx. 0.38 m
Cable 4 x 1.5 mm
2
Length approx. 0.38 m
PE connection At the housing with M5
stud
At the housing with M5
stud
At the housing with M5
stud
Degree of protection IP20 or IPXXB IP20 or IPXXB IP20 or IPXXB
Weight kg 1.2 1.3 1.3
