Cabinet design and EMC for components, Blocksize format
9.8 Notes on electrical cabinet cooling
Manual
270 Manual, 01/2011, 6SL3097-4AC10-0BP2
9.8.3.3 Power loss for line reactors and line filters
Table 9- 11 Overview of power loss during rated operation for line reactors and line filters
Rated output current I
n
Frame size Line supply voltage Unit Power loss
50/60 Hz
Line reactors for Blocksize PM340
0.9 A/2.3 A FSA 1-ph. 200 to 240 V AC W 12.5/15
3.9 A FSA 1-ph. 200 to 240 V AC W 11.5/14.5
1.3 A/1.7 A FSA 3-ph. 380 to 480 V AC W 6 / 7
2.2 A/3.1 A FSA 3-ph. 380 to 480 V AC W 12.5/15
4.1 A FSA 3-ph. 380 to 480 V AC W 7.5/9
5.9 A/7.7 A FSB 3-ph. 380 to 480 V AC W 9 / 11
10.2 A FSB 3-ph. 380 to 480 V AC W 27 / 32
18 A/25 A FSC 3-ph. 380 to 480 V AC W 98 / 118
32 A FSC 3-ph. 380 to 480 V AC W 37 / 44
38 A/45 A/60 A FSD 3-ph. 380 to 480 V AC W 90 / 115
75 A/90 A FSE 3-ph. 380 to 480 V AC W 170 / 215
110 A/145 A/178 A FSF 3-ph. 380 to 480 V AC W 280 / 360
Line filters for Blocksize PM340 FSA 3-ph. 380 to 480 V AC W < 5
