Mains connection and line-side power components
2.7 Line filter
Manual
42 Manual, 01/2011, 6SL3097-4AC10-0BP2
2.7.5 Technical data, Blocksize line filter
Table 2- 1 Technical data, Blocksize line filter
Line supply voltage 3-ph. 380...480 V AC
Line filter 6SE6400-2FA00-6AD0
Suitable for Power Module 6SL3210-1SE11-3UA0, 6SL3210-1SE11-7UA0
6SL3210-1SE12-2UA0, 6SL3210-1SE13-1UA0
6SL3210-1SE14-1UA0
Rated current A 6
Power loss W < 5
Line supply connection
L1, L2, L3
2.5 mm screw terminals
2
PE connection At the housing with M4 stud
Load connection
U, V, W
Shielded cable 3 x 2.5 mm
2
0.4 m long
Degree of protection IP20 or IPXXB
Weight, approx. kg 0.5
