Power Modules
3.1 Power Modules Blocksize (PM340)
Manual
88 Manual, 01/2011, 6SL3097-4AC10-0BP2
3.1.6.2 Mounting dimensions and tightening torques
The mounting dimensions and the tightening torques for fixing the Power Modules are
specified in the following table.
Table 3- 7 PM340, dimensions and tightening torques for mounting
Frame size Height, width, depth Dimensions
(with Control Unit)
Retaining type Tightening torques
mm 173 x 73 x 145 FSA HxWxD
Inches 6.81 x 2.87 x 5.71
2 x M4 studs,
2 x M4 nuts,
2 x M4 washers
mm 270 x 153 x 165 FSB HxWxD
Inches 10.63 x 6.02 x 6.50
4 x M4 studs,
4 x M4 nuts,
4 x M4 washers
mm 334 x 189 x 185 FSC HxWxD
Inches 13.1 x 7.41 x 7.28
4 x M5 studs,
4 x M5 nuts,
4 x M5 washers
2.5 Nm with washers
mm 419 x 275 x 204 FSD
without line
filter
HxWxD
Inches 16.3 x 10.8 x 8.0
mm 512 x 275 x 204 FSD
with
integrated line
filter
HxWxD
Inches 20.1 x 10.8 x 8.0
mm 499 x 275 x 204 FSE
without line
filter
HxWxD
Inches 19.6 x 10.8 x 8.0
mm 635 x 275 x 204 FSE
with
integrated line
filter
HxWxD
Inches 25 x 10.8 x 8.0
4 x M6 studs,
4 x M6nuts,
4 x M6 washers
6 Nm with washers
mm 635 x 350 x 316 FSF
without line
filter
HxWxD
Inches 25.0 x 13.8 x 12.4
mm 934 x 350 x 316 FSF
with
integrated line
filter
HxWxD
Inches 36.8 x 13.8 x 12.4
4 x M8 studs,
4 x M8 nuts,
4 x M8 washers
13 Nm with washers
Table 3- 8 PM340, load terminals - Tightening torques
Frame size Tightening torques
FSA Nm 1.1
FSB Nm 1.5
FSC Nm 2.25
FSD Nm 6
FSE Nm 6
FSF Nm 13
