Motor-side power components
5.1 Motor reactors (blocksize)
Manual
148 Manual, 01/2011, 6SL3097-4AC10-0BP2
5.1.6 Technical data
Table 5- 10 Motor reactors for Power Modules 3-ph. 380 V to 480 V AC, frame size FSA
Motor reactor (for a 4 kHz pulse frequency)
Order number 6SE6400-3TC00-4AD2
Frame size FSA FSA FSA FSA FSA
Suitable for Power Module 6SL3210-
1SE11-3UA0
6SL3210-
1SE11-7UA0
6SL3210-
1SE12-2UA0
6SL3210-
1SE13-1UA0
6SL3210-
1SE14-1UA0
Rated current A 4.5
Power loss kW 0.005
Connection to the Power
Module
Cable 4 x 1.5 mm
2
Length approx. 0.3 m
Motor connection Screw terminals for cable cross-section 6 mm
2
PE connection M5 stud
Max. permissible cable
length between motor
reactor and motor
m 100 (shielded)
150 (unshielded)
100 (shielded)
225 (unshielded)
Degree of protection IP20 or IPXXB
Weight, approx. kg 2
Rated current I
rated
of the Power Module
A 1.3 1.7 2.2 3.1 4.1
Table 5- 11 Motor reactors for Power Modules 3-ph. 380 V to 480 V AC, frame sizes FSB and FSC
Motor reactor (for a 4 kHz pulse frequency)
Order number 6SL3202-0AE21-0CA0 6SL3202-0AJ23-2CA0
Frame size FSB FSB FSB FSC FSC FSC
Suitable for Power
Module 6SL3210-
1SE16-0xxx 1SE17-7xxx 1SE21-0xxx 1SE21-8xxx 1SE22-5xxx 1SE23-2xxx
Rated current A 10 25
Power loss kW 0.02 0.06
Connection to the
Power Module
Cable 4 x 1.5 mm
2
Length approx. 0.4 m
Cable 4 x 1.5 mm
2
Length approx. 0.35 m
Motor connection Screw-type terminals for cable cross-section
6 mm
2
Screw-type terminals for cable cross-
sections 2.5 mm
2
to 10 mm
2
PE connection M5 stud M5 stud
Max. permissible
cable length
between motor
reactor and motor
m 100 (shielded)
150 (unshielded)
Degree of protection IP20 or IPXXB
Weight, approx. kg 4.5 9
Rated current I
rated
of the Power Module
A 5.9 7.7 10 18 25 32
