Mains connection and line-side power components
2.7 Line filter
Manual
38 Manual, 01/2011, 6SL3097-4AC10-0BP2
2.7 Line filter
2.7.1 Description
In conjunction with a suitably EMC-compliant system configuration, line filters limit the
conducted interference emitted by the Power Modules to the limit values of Category C2 acc.
to EN 61800-3.
A separate line filter (see catalog) must be used for the SINAMICS S110 drive line-up.
Note
All PM340 Power Modules are available with integrated line filters.
This does not apply, however, to frame size FSA for a 3-ph. 380 to 480 V AC line supply
voltage; an external line filter is required here.
NOTICE
An additional line filter must be used to suppress interference in other loads. To prevent
mutual interference, this line filter must not be equipped with line-side capacitors with
respect to ground. Filter series B84144A*R120 (EPCOS) is recommended.
Note
According to product standard EN 61800-3, RFI suppression commensurate with the
relevant rated conditions must be provided and is a legal requirement in the EU (EMC
Directive). Line filters and/or line reactors are required for this purpose. The use of filters of
other makes can lead to limit value violations, resonances, overvoltages and irreparable
damage to motors or other equipment. The machine manufacturer must provide verification
that the machinery to be operated with the drive products and the installed suppression
elements, e.g. line filters, are CE/EMC-compliant before the machines are approved for
delivery.
