Motor-side power components
5.1 Motor reactors (blocksize)
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
137
%
%
&
&
$
$
)UDPHVL]H)6&
)UDPHVL]H)6%
Figure 5-2 Dimension drawing: Motor reactor, frame sizes FSB and FSC
Table 5- 2 Total dimensions: Motor reactor, frame sizes FSB and FSC
Motor reactor
6SL3202-
0AE21-0CA0
0AJ23-2CA0
Frame size FSB FSC
Dimension A in mm and (inches) 270 (10.62) 334 (13.14)
Dimension B in mm and (inches) 153 (6.02) 189 (7.44)
Dimension C in mm and (inches) 70 (2.75) 50 (1.96)
