Power Modules
3.2 Power Modules Blocksize Liquid Cooled (PM340)
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
107
DANGER
The drive components generate high leakage currents in the protective conductor. The
components must only be operated in cabinets or in closed electrical operating areas and
must be connected with the protective conductor. To protect against electric shock, the
protective conductor connection on the cabinet or machine must be implemented in
accordance with one of the following measures:
stationary connection and protective conductor connection by means of ≥ 10 mm
2
Cu or
≥ 16 mm
2
Al
stationary connection and automatic shutdown of the power supply if the protective
conductor is interrupted
DANGER
The hazard warning in the local language for the DC link discharge time must be affixed to
the component. A set of labels bearing this warning in 16 languages is provided with the
component.
WARNING
Power Modules must be mounted in the vertical position.
For the Liquid Cooled Power Modules, a cooling clearance of 300 mm (11.81 inch) must be
maintained above and below the component.
Cooling clearances of 30 mm (1.18 inch) must be observed in front of the component.
Devices that could restrict the cooling air flow may not be mounted/installed in this area.
It must be carefully ensured that the cooling air flow of the Power Modules can flow
unrestricted.
Note
The Power Modules with frame sizes FSD, FSE, and FSF can be mounted without any
lateral clearance.
DANGER
Cable shields and unused power cable conductors (e.g. brake conductors) must be
connected to PE potential to prevent capacitive cross-talk charges.
Non-observance can cause lethal shock voltages.
WARNING
The equipment must be safely disconnected from the supply before any installation or
service work is carried out on cooling circuit components.
The cooling circuit may only be connected by a trained specialist.
