Cabinet design and EMC for components, Blocksize format
9.2 Safety information
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
253
Note
When installing the equipment in cabinets, the ventilation slots must be covered to prevent
drill swarf, wire end ferrules, and the like from falling into the housing.
Safety regulations governing shock protection must be observed. See also EN 60204–1.
