Power Modules
3.1 Power Modules Blocksize (PM340)
Manual
64 Manual, 01/2011, 6SL3097-4AC10-0BP2
Power Module frame size FSC, with and without
integrated line filter
Power Module frame size FSD, with and without integrated line
filter
Power Module frame size FSE, with and without
integrated line filter
Power Module frame size FSF, with and without integrated line
filter
