User’s Manual of WGS3-2820/WGS3-5220
21
Supports VLAN
− IEEE 802.1Q VLAN
− GARP/GVRP/GMRP
− Up to 4041 VLANs, out of 4041 VLAN IDs
− Protocol-Based VLAN
Supports Spanning Tree Protocol
− STP, IEEE 802.1d
− RSTP, IEEE 802.1w
− MSTP, IEEE 802.1s
Supports Link Aggregation
− up to 8 trunk groups
− up to 8 ports per trunk group
− 802.3ad Link Aggregation and LACP
− Cisco ether-channel (Static Trunk)
Provides Port Mirror (many-to-1)
Routing Features
Supports RIP v1 and v2
Supports OSPF v1/v2
Supports router discovery (IRDP)
Supports VLAN routing
Supports VRRP
Supports IP routing
Supports route redistribution
Supports route preferences
Multicast
Supports PIM-DM and PIM-SM
Supports DVMRP
Supports IGMP v1/v2/v3
Security
User/Password protected system management
L2/L3/L4 ACL (access control list)
RADIUS client
TACACS client
SSH v1/v2
SSL v3/TLS v1
IEEE 802.1x Port-Based Authentication
Port MAC lock
