User’s Manual of WGS3-2820/WGS3-5220
347
8.6 Device Configuration Commands
8.6.1 addport
This command adds one port to the port-channel (LAG). The first interface is a logical slot and port number of a configured
port-channel.
▫ Format addport <logical slot/port>
▫ Mode Interface Config
#Note:
Before adding a port to a port-channel, set the physical mode of the port. See 'speed' command.
8.6.2 auto-negotiate
This command enables automatic negotiation on a port. The default value is enable.
▫ Format auto-negotiate
▫ Mode Interface Config
8.6.2.1 no auto-negotiate
This command disables automatic negotiation on a port.
▫ Format no auto-negotiate
▫ Mode Interface Config
8.6.3 auto-negotiate all
This command enables automatic negotiation on all ports. The default value is enable.
▫ Format auto-negotiate all
▫ Mode Global Config
8.6.3.1 no auto-negotiate all
This command disables automatic negotiation on all ports.
▫ Format no auto-negotiate all
▫ Mode Global Config
8.6.4 delete interface
This command deletes an existing port-channel (LAG) from the configuration. The interface is a logical slot and port for a
configured port-channel. The all option removes all configured port-channels (LAGs).
▫ Format delete interface { <logical slot/port> | all}
▫ ModeInterface Config
