User’s Manual of WGS3-2820/WGS3-5220
369
8.6.62.1 no storm-control broadcast
This command disables broadcast storm recovery mode.
The threshold implementation follows a percentage pattern. If the broadcast traffic on any Ethernet port exceeds the high
threshold percentage (as represented in "Broadcast Storm Recovery Thresholds" table) of the link speed, the switch discards
the broadcasts traffic until the broadcast traffic returns to the low threshold percentage or less. The full implementation is
depicted in the "Broadcast Storm Recovery Thresholds" table.
▫ Format no storm-control broadcast
▫ Mode Global Config
Link Speed High Low
10M 20 10
100M 5 2
1000M 5 2
8.6.63 storm-control flowcontrol
This command enables 802.3x flow control for the switch.
▫ Default Disabled
▫ Format storm-control flowcontrol
▫ Mode Global Config
#Note:
This command only applies to full-duplex mode ports.
8.6.63.1 no storm-control flowcontrol
This command disables 802.3x flow control for the switch.
"Note: This command only applies to full-duplex mode ports.
▫ Format no storm-control flowcontrol
▫ Mode Global Config
8.6.64 vlan
This command creates a new VLAN and assigns it an ID. The ID is a valid VLAN identification number (ID 1 is reserved for the
default VLAN). VLAN range is 2-4094.
▫ Format vlan <2-4094>
▫ Mode VLAN database
8.6.64.1 no vlan
