▫ ModeInterface Config
8.6.60 speed
This command sets the speed and duplex setting for the interface.
▫ Format speed {{100 | 10} {half-duplex | full-duplex} | 1000 fullduplex}
▫ ModeInterface Config
Acceptable values are:
100h 100BASE-T half-duplex
100f 100BASE-T full duplex
10h 10BASE-T half duplex
10f 100BASE-T full duplex
8.6.61 speed all
This command sets the speed and duplex setting for all interfaces.
▫ Format speed all {{100 | 10} {half-duplex | full-duplex} | 1000 fullduplex}
▫ Mode Global Config
Acceptable values are:
100h 100BASE-T half-duplex
100f 100BASE-T full duplex
10h 10BASE-T half duplex
10f 100BASE-T full duplex
8.6.62 storm-control broadcast
This command enables broadcast storm recovery mode. If the mode is enabled, broadcast storm recovery with high and low
thresholds is implemented.
The threshold implementation follows a percentage pattern. If the broadcast traffic on any Ethernet port exceeds the high
threshold percentage (as represented in "Broadcast Storm Recovery Thresholds" table) of the link speed, the switch discards
the broadcasts traffic until the broadcast traffic returns to the low threshold percentage or less. The full implementation is
depicted in the "Broadcast Storm Recovery Thresholds" table.
▫ Format storm-control broadcast
▫ Mode Global Config
Link Speed High Low
10M 20 10
100M 5 2
1000M 5 2
Table 7-1 Broadcast Storm Recovery Thresholds
