User’s Manual of WGS3-2820/WGS3-5220

Standards Compliance

IEEE 802.3

IEEE 802.3u

IEEE 802.3z

IEEE 802.3ab

IEEE 802.3x

IEEE 802.3ad

IEEE 802.1d

IEEE 802.1w

IEEE 802.1s

IEEE 802.1p

IEEE 802.1Q

10BASE-T

100BASE-TX/100BASE-FX

Gigabit SX/LX

Gigabit 1000Base-T

Flow Control

Port trunk with LACP

Spanning tree protocol

Rapid Spanning tree protocol

Multiple Spanning Tree Protocol

Class of service

VLAN Tagging
