Si341009 Troubleshooting by Remote Controller
Troubleshooting 94
k: ON h: OFF l: Blink
Error code
Operation
lamp
Error contents Page
Referred
Outdoor Unit E1 l PCB abnormality 99
E3 l High pressure abnormality 100
E4 l Actuation of low pressure sensor 102
E5 l Inverter compressor motor lock 104
E6 l STD compressor motor overcurrent/Lock 106
E7 l Outdoor unit fan motor abnormality 107
E9 l Electronic expansion valve coil Abnormality (Y1E ~ Y3E) 110
F3 l Abnormal discharge pipe temperature 112
F6 l Refrigerant overcharged 114
H3 l High pressure switch system abnormality 115
H7 l Abnormal outdoor fan motor signal 116
H9 l Abnormal outdoor air thermistor 118
J1 l High pressure sensor abnormality 119
J2 l Currents sensor abnormality 121
J3 l Abnormal discharge pipe thermistor 118
J5 l Abnormal suction pipe thermistor 118
J6 l Abnormal heat exchanger thermistor 118
J7 l Abnormal liquid pipe thermistor 118
J8 l Abnormal receiver gas vent outlet thermistor 118
J9 l Abnormal subcooling heat exchanger outlet thermistor 118
JA l High pressure sensor abnormality 122
JC l Low pressure sensor abnormality 124
L1 l Inverter PCB abnormality 126
L4 l Inverter radiating fin temperature rise 127
L5 l Momentary overcurrent of inverter compressor 128
L8 l Overcurrent abnormal of inverter compressor 130
LA l Power unit abnormality —
LC l Transmission system abnormality (between inverter and main PCB) 134
P1 l Inverter over-ripple protection 136
P4 l Thermistor and replaced abnormality 138
PJ l Faulty field setting after replacing main PCB or faulty combination of PCB 139
System U0 k Refrigerant shortage 140
U1 l Reverse phase, open phase 142
U2 l Power supply insufficient or instantaneous failure 143
U3 l Check operation is not executed 146
U4 l Transmission error (between indoor and outdoor units) 147
U5 l Transmission error (between remote controller and indoor unit) 150
U7 l Transmission error (Across outdoor units) 151
U8 l Transmission error (between main and sub remote controllers) 157
U9 l Transmission error (between indoor and outdoor units in the same system) 158
UA l Improper combination of indoor and outdoor units, indoor units and remote
controller
159
UC k Address duplication of centralized controller 163
UE l Transmission error (between centralized controller and indoor unit) 164
UF l System is not set yet 167
UH l System, refrigerant system address undefined 168
