Capacity Range Si341009
7 General Information
4. Capacity Range
Combination ratio
Connection capacity: 50% - 130%
Note: * When outdoor-air processing units (FXMQ-MF) and standard indoor units are connected, the total connection
capacity of the outdoor-air processing units (FXMQ-MF) must not exceed 30% of the capacity index of the
outdoor units.
Outdoor unit combinations
*1. For multiple connections of 18 HP systems and above, the outdoor unit multi connection piping kit (separately sold)
is required.
*2. Total capacity index of connectable indoor units must be 50%–130% of the capacity index of the outdoor units.
*3. When outdoor-air processing units (FXMQ-MF) and standard indoor units are connected, the total connection
capacity of the outdoor-air processing units (FXMQ-MF) must not exceed 30% of the capacity index of the outdoor
units.
Combination ratio =
Total capacity index of the indoor units
Capacity index of the outdoor units
Type
Min.
combination
ratio
Max. combination ratio
Types of connected indoor units Type of connected Air Treatment Equipments
Standard indoor units
VKM FXMQ-MF
When VKM is
only
connected
When VKM
and indoor
units are
connected
When
FXMQ-MF is
only
connected
When
FXMQ-MF
and indoor
units are
connected
Single outdoor units
50% 130% 130% 130% 100% 100%*Double outdoor units
Triple outdoor units
HP
Capacity
index
Model name Combination
Outdoor unit multi
connection piping kit
*1
Total capacity index of
connectable indoor units
*2 *3
Maximum
number of
connectable
indoor units
Combination (%)
50% 100% 130%
8 HP 200 RQYQ8PY1 RQYQ8PY1 — 100 200 260 13
10 HP 250 RQYQ10PY1 RQYQ10PY1 — 125 250 325 16
12 HP 300 RQYQ12PY1 RQYQ12PY1 — 150 300 390 19
14 HP 350 RQYQ14PY1 RQYQ14PY1 — 175 350 455 22
16 HP 400 RQYQ16PY1 RQYQ16PY1 — 200 400 520 26
18 HP 450 RQYQ18PY1 RQYQ8PY1 + RQYQ10PY1
BHFP22P100
225 450 585 29
20 HP 500 RQYQ20PY1 RQYQ8PY1 + RQYQ12PY1 250 500 650 32
22 HP 550 RQYQ22PY1 RQYQ10PY1 + RQYQ12PY1 275 550 715 35
24 HP 600 RQYQ24PY1 RQYQ12PY1 + RQYQ12PY1 300 600 780 39
26 HP 650 RQYQ26PY1 RQYQ10PY1 + RQYQ16PY1 325 650 845 42
28 HP 700 RQYQ28PY1 RQYQ12PY1 + RQYQ16PY1 350 700 910 45
30 HP 750 RQYQ30PY1 RQYQ14PY1 + RQYQ16PY1 375 750 975 48
32 HP 800 RQYQ32PY1 RQYQ16PY1 + RQYQ16PY1 400 800 1,040 52
34 HP 850 RQYQ34PY1
RQYQ10PY1 + RQYQ10PY1 + RQYQ14PY1
BHFP22P151
425 850 1,105 55
36 HP 900 RQYQ36PY1
RQYQ10PY1 + RQYQ10PY1 + RQYQ16PY1
450 900 1,170 58
38 HP 950 RQYQ38PY1
RQYQ10PY1 + RQYQ12PY1 + RQYQ16PY1
475 950 1,235 61
40 HP 1,000 RQYQ40PY1
RQYQ12PY1 + RQYQ12PY1 + RQYQ16PY1
500 1,000 1,300
64
42 HP 1,050 RQYQ42PY1
RQYQ10PY1 + RQYQ16PY1 + RQYQ16PY1
525 1,050 1,365
44 HP 1,100 RQYQ44PY1
RQYQ12PY1 + RQYQ16PY1 + RQYQ16PY1
550 1,100 1,430
46 HP 1,150 RQYQ46PY1
RQYQ14PY1 + RQYQ16PY1 + RQYQ16PY1
575 1,150 1,495
48 HP 1,200 RQYQ48PY1
RQYQ16PY1 + RQYQ16PY1 + RQYQ16PY1
600 1,200 1,560
