Si341009 Specifications
Specifications 12
Note:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name RQYQ16PY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 39,000
Btu / h 155,000
kW 45.3
★2 Cooling Capacity (19.0°CWB)
kW
45.0
★3 Heating Capacity
kcal / h 43,000
Btu / h 171,000
kW 50.0
Casing Colour Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1680×1240×765
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Compressor
Displacement Volume
m³/h 13.34+10.53+10.53
Number of Revolutions r.p.m 6300, 2900, 2900
Motor Output×Number
of Units
kW (2.7+4.5+4.5)×1
Starting Method Soft Start
Fan
Type Propeller Fan
Motor Output kW 0.35×2
Airflow Rate m³/min 233
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 381
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 10~100
Refrigerant
Refrigerant Name R-410A
Charge kg 11.7
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. C: 4D069106A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
