Si341009 Troubleshooting by Remote Controller
Troubleshooting 108
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
A
RQYQ8PY1
RQYQ10PY1
RQYQ12PY1
RQYQ14PY1
RQYQ16PY1
NO
Remove the foreign matters.
Are any foreign
matters around the
fan?
Check fan motor (fan motor1, 2) corresponding to error
code “E7” in the monitor mode of outdoor unit PCB.
Check in the monitor mode
Turn OFF the power supply and wait for 10 minutes.
{
Fan motor1: relay connector X1A, X2A or X1A, X2A of
compressor INV. PCB.
{
Fan motor1, 2: relay connector X3A, X4A or X1A, X2A of
compressor INV. PCB.
Check the connection status of the connectors
Is any connector
disconnected?
{
Fan motor1: Both power supply wire and signal wire are all
white.
{
Fan motor2: Both power supply wire and signal wire are
red (on PCB side) or white (on motor side).
Check the color of relay connectors
Relay
connectors have
any connection
error.
Insert the connector.
Correct the connection of the relay
connectors.
YES
YES
NO
YES
NO
