Si341009 Troubleshooting by Remote Controller
Troubleshooting 118
2.17 Thermistor System Abnormality
Remote
Controller
Display
H9, J3, J5, J6, J7, J8, J9
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
The error is detected according to the temperature detected by each individual thermistor.
Error Decision
Conditions
When thermistor is disconnected or short-circuited during operation
Supposed
Causes
Defective thermistor
Defective connection of connector
Defective outdoor unit PCB (control PCB)
Troubleshooting
Error code Defective thermistor
RXYQ8PY1
RXYQ10 • 12PY1 RXYQ14 • 16PY1
Symbol
Connector
Symbol
Connector
Symbol
Connector
H9
Outdoor air thermistor R1T X18A R1T X18A R1T X18A
J3
Discharge pipe thermistor
R3T X29A R31T
X29A
R31T
X29A— — R32T R32T
————R33T
J5
Suction pipe thermistor R8T X11A R8T X11A R8T X11A
J6
Heat exchanger thermister R9T X12A R9T X12A R9T X12A
J7
Liquid pipe thermistor R6T X30A R6T X30A R6T X30A
J8
Reiceiver gas vet outlet thermistor R7T X30A R7T X30A R7T X30A
Reiceiver liquid level thermistor R2T X30A R2T X30A R2T X30A
Refrigerant regulator liquid pipe thermistor R4T X30A R4T X30A R4T X30A
J9
Subcooling heat exchanger outlet thermistor R5T X30A R5T X30A R5T X30A
Connect correctly.
Normal?
Replace the outdoor unit control
PCB (A1P).
NO
Caution
Be sure to turn off power switch before connect or disconnect connector, or parts damage may be occurred.
Remove thermistor from outdoor unit
PCB, then measure the resistance
using a tester.
Check connectors for connection.
YES
Replace the thermistor.
Normal?
NO
YES
