Si341009 Field Setting from Outdoor Unit
Test Operation 66
No. Setting item Description
35
Setting of difference
in height for the
outdoor unit
Make the setting when the outdoor unit is installed 40 m
or more below the indoor unit.
38
Emergency
operation
(Setting for the
master unit
operation
prohibition in multi-
outdoor-unit
system)
Used to temporarily prohibit the applicable outdoor unit
from operating should there be any faulty part in multi-
outdoor-unit system. Since the comfortable environment
is extremely impaired, prompt replacement of the part is
required.
39
Emergency
operation
(Setting for the
slave unit 1 and 2
operation
prohibition in multi-
outdoor-unit
system)
40
Emergency
operation
(Setting for the
slave unit 3
operation
prohibition in multi-
outdoor-unit
system)
55
Master-slave set-up
for multi outdoor
units
Set up master and slave units for multi-connection
outdoor units.
After setting up, press the button for 5
seconds or more.
The numbers in the "No." column represent the number of times to press
the SET (BS2) button.
BS5 (RESET)
