Troubleshooting by Remote Controller Si341009
135 Troubleshooting
Troubleshooting
Note:
*1. Disconnect the connector once, then reconnect it and check that it is securely connected.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Are the
connectors of the
main PCB, and
inverter PCB all securely
connected?
(*1)
Is the type of
the inverter PCB
correct?
The INV.
compressor has
insulation resistance of
not more than
100kΩ.
The fan
motor has insulation
resistance of not more
than 1MΩ.
Replace it with a correct PCB.
Properly connect the connectors.
Replace the INV. compressor
(M1C).
Replace the fan motor.
NO
NO
YES
YES
NO
YES
YES
NO
YES
NO
NO
NO
YES
The LC error recurs.
The
micro-computer
normal monitor (green)
of the main PCB (A1P)
is blinking.
The
micro-computer
normal monitor (green)
of the inverter PCB (A4P)
is blinking.
Not the LC error. Check the error
code again.
Replace the main PCB (A1P).
Continue the operation.
(It is supposed that the error
results from causes such as
instantaneous power failure.)
Replace the inverter PCB (A4P).
YES
